Hydraulic Test Bench ▸ Single station demonstration bench

HydroShow-one

Single station demonstration bench

Simplicity of use
Very compact and transportable equipment

+33 2 52 56 04 20

Request a quote

Maximum pressure of the pressure generator

6 bar

Temperature measurement

± 0,3°C

Pressure measurement

± 0.02 bar

Products tested

Sector of activity

Main functions

The single-user faucet demonstration bench allows simple tests to be carried out on all types of faucets (electronic faucets, mixing faucets, mechanical mixing faucets, thermostatic mixing faucets, simple faucets, timed faucets).

This equipment is designed for specialist shops that wish to have a system that allows them to carry out quick tests or to demonstrate the correct operation of a tap. The system can also be used to demonstrate the operation of a tap at trade fairs or in a showroom.

Operating mode

Discover how our Single Station Demo Bench works

After installing the taps to be tested, the user sets the independent inlet pressures (hot / cold water). The bench manages the pressure control.

The screen displays the pressure, temperature and flow measurements of hot and cold water.

Functions

flow rate measurement
temperature measurement
regulation and measurement of inlet pressures
regulation and measurement of inlet pressures

independent pressure variation on hot and cold

measuring the flow rate of water from the hard point on a mechanical mixing valve (corresponds to the “economy” position)
limiting the temperature of the mechanical mixing valve
ensuring the correct temperature setting of a thermostatic mixing valve
measuring the flow rate and duration of flow on a timed mixing valve

HydroShow-One – Hydraulic test bench – LF Technologies

HydroShow-One - Hydraulic test bench - LF Technologies

Timed mixing valves

Flow rate and hardness can be measured on a timed mixing valve.

Mechanical mixing valve

This bench can be used to test the water flow from the hard point or the temperature limitation of the mixing valve.

Benefits of HydroShow-one

Simple parameterization

The bench is equipped with two pressure set point controls (EC/EF) for easy bench adjustment.

Compact solution

Ergonomic, very compact and easily transportable.

Independent adjustment

The EC pressure is set independently of the EF pressure.

Extendable sink

The bench has two sinks to suit the type of tap being tested.

TECHNICAL SPECIFICATIONS of the Single station demonstration bench

Features	HydroShow-one15	HydroShow-one25	HydroShow-one35
Maximum flow	2×15 l/min	2×25 l/min	2×35 l/min
Maximum pressure of pressure generator	6 bar	6 bar	6 bar
Pressure generator minimum pressure	Bench supply pressure	Bench supply pressure	Bench supply pressure
Pressure measurement	± 0,02 bar	± 0,02 bar	± 0,02 bar
Temperature measurement	± 0,3°C	± 0,3°C	± 0,3°C
Flow measurement	± 0,3 l/min	± 0,3 l/min	± 0,6 l/min

OPTIONS

Antiscald test

The anti-scald test function is used to check the behavior of a thermostatic mixing valve when the cold water supply is suddenly cut off, in order to verify whether there is a risk of scalding for the user of the faucet.
